          NND-200 NMEA DISTRIBUTOR



              Published on: 2021-10-01



          【FEATURES】
          -NND-200 is a NMEA distributor/buffer to provide 8 NMEA outputs from 4 inputs.
          -The baud rate can be up to 38400bps from 4800bps, while the default rate is set as 4800bps.
          -With a built-in optical-coupled isolator, the distributor is a reliable and professional device, which can be used on board. The external equipment connected to the distributor can be safely protected from lightning surges on line.
          -NND-200 contains two NMEA buffers:
          Buffer 1: 2 inputs/4 outputs. When used for GNSS buffer, all 4 NMEA outputs will keep on unless both GNSS inputs fail simultaneously. When both Input 1 and Input 2 are valid, only Input 1 will be selected as default.
          Buffer 2: 2 inputs/4 outputs. Same as Buffer 1.
          -Buffer 1 and Buffer 2 can be combined into a new buffer with 4 inputs/8 outputs.
          【SPECIFICATIONS】
          Model No：
           NND-200
          Type of Interface：
           RS485/RS422
          Standards：
           Conform to IEC 61162-1, IEC 61162-2, NMEA 0183 Standards
          Number of Inputs：
           4
          Number of Outputs：
           8
          Operation Mode：
           Semi-duplex
          Power Supply：
           DC24V, 300mA
          LED Indicators：
           NMEA inputs, NMEA outputs
          Baud Rate：
           4800bps～38400bps (default 4800bps)
          Cable Length：
           0-5km
          Size：
           35 (H) × 255 (W) ×175 (D) mm
          Working Environment：
           -40℃～85℃, relative humidity 5% to 95%



          NSR NND-200 NMEA DISTRIBUTOR BROCHURE.pdf
